Molten Steel Sampling Ladle
This specialized instrument is designed for the rapid and safe acquisition of molten steel samples. Featuring a robust refractory material construction, it ensures thermal stability and prevents contamination during the sampling process.
Technical Specifications
Overview
High-Precision Molten Steel Sampling
This specialized sampling instrument is designed for the rapid and safe acquisition of molten steel samples, suitable for both deoxidized and non-deoxidized applications. It facilitates quick analysis of chemical ingredients including carbon, manganese, sulfur, and phosphorus, as well as dissolved gases like hydrogen and oxygen. Engineered for efficiency, the sampler improves steel quality and reduces waste ratios in demanding foundry and steel mill environments.
Technical Specifications
Sampling Efficiency
90 %
Efficiency
Performance Features
- Rapid sampling time
- Easy operation
- High thermal stability
- Resistant to high temperatures and corrosive slags
- Standard Sample Size
- 34 x 12 mm (Outer Diameter x Thickness)
- Classification
- Direct insertion typeDecanting type
Model Comparison
Sampler Model Specifications
| Model | Deoxidizer | Sample Size (ODxT) | Inlet OD/Length |
|---|---|---|---|
| W G Q A | None | Φ34×12 | Φ7×(20-45) |
| W G Q B | None | Φ30×15 | Φ7×(20-30) |
| W G Q B L | Al/Zirconium | Φ34×12 | Φ6×(20-30) |
| W G Q A L | Al/Zirconium | Φ34×12 | Φ7×(20-45) |
| W T Q | None | Φ35×14 | Φ10×1.5 |
| W T Q C | None | Φ6×50 | N/A |
