Technical Specifications
Overview
Precision Heavy Load Transport
This modular air caster system is engineered for the efficient and precise movement of heavy loads within manufacturing and warehousing environments. By utilizing a thin film of compressed air between the load and the floor, the system achieves near-frictionless movement. It features a flexible, wear-resistant urethane diaphragm design that ensures durability and reliable performance for over a decade of industrial use.
Technical Specifications
Load Capacity Range
10 MT
Minimum Capacity
100 MT
Maximum Capacity
Module Configuration
- Four air modular system
- Six air modular system
- Power Source
- Compressed air
- Diaphragm Material
- Wear-resistant urethane
Performance
Expected Service Life
10+ Years
- System Advantages
- Omnidirectional movementPrecise positioningMinimal floor damageNear-frictionless travel
System Components
System Components
| Component | Function |
|---|---|
| Air Caster Modules | Generate air film for lifting |
| Control Unit | Regulates pressure to modules |
| Air Hoses | Connects modules to control unit |
