Air Bearing Casters with Six Air Modules
Air bearing casters utilize a thin film of air to float heavy loads, enabling smooth and omnidirectional movement. This system includes six air modules connected to a central control unit.
Technical Specifications
Product Overview
Precision Air Bearing System
This air bearing caster system utilizes a thin film of compressed air to float heavy loads, enabling smooth, omnidirectional movement across industrial floor surfaces. Designed for heavy machinery and equipment relocation, the system minimizes friction and prevents floor damage by eliminating direct contact. The complete setup includes a central control unit and six air modules, ensuring stable and efficient weight distribution for delicate or heavy industrial items.
Technical Specifications
- Air Modules
- 6 units
- Main Air Tube Length
- 30 m
- Vice Air Tube Length
- 6 m
- Power Source
- Compressed Air
Operational Requirements
Floor Surface Requirements
- Smooth surface
- No sharp fragments
- No gaps or cracks
- Dry surface (no water)
Performance Benefits
Floor ProtectionNon-MarkingOmnidirectional MovementLow Friction
- Compatible Floor Types
- CementPolyurethane
