Marine Centrifugal Vortex Pump
This centrifugal vortex pump is designed for marine applications. It is used for pumping fresh and sea water for drinking, washing, and sanitation.
Technical Specifications
Overview
Marine Centrifugal Vortex Pump
The CWX series electromotive centrifugal vortex pumps are specialized marine solutions designed for pumping both fresh and sea water. These pumps are ideal for essential shipboard applications including drinking water supply, washing, and sanitation systems. Combining centrifugal and vortex technologies, they offer reliable self-priming capabilities and the ability to handle fluids with entrained air or gases.
- Primary Applications
- Drinking WaterWashingSanitationMarine Fluid Transfer
Technical Features
Pump Technology
- Centrifugal Vortex hybrid design
- Self-priming capability
- Dynamically balanced impeller
- Corrosion-resistant casing
Fluid Compatibility
Model Nomenclature
Model Code Instruction
| Code Segment | Description |
|---|---|
| 1.5 | Inlet/outlet diameter divided by 25 |
| C | Marine pump designation |
| WX | Centrifugal vortex pump type |
| 2, 3, 4 | Contrast revolution divided by 10 |
| A | First improvement and bracket support |
Model Identification
Available Models
- 1.5CWX-2A
- 1.5CWX-3A
- 1.5CWX-4A
- 1.5CWX-2
- 1.5CWX-3
- 1.5CWX-4
Design & Construction
Robust and Compact Design
The pump features a robust construction with precision-engineered internal components, including high-quality gears and seals to ensure longevity in demanding marine environments. Its compact and modular design facilitates easy installation and maintenance, while the self-priming function eliminates the need for external priming, reducing operational downtime.
