Marine Bronze Angle Check Valve
This marine bronze angle check valve prevents backflow in piping systems. Its angled body allows efficient flow and compact installation.
Technical Specifications
Product Overview
Marine-Grade Flow Control
This Marine Bronze Angle Check Valve is engineered to effectively prevent backflow in critical piping systems. Constructed from high-quality bronze materials, it offers exceptional corrosion resistance suitable for demanding marine environments, including seawater, freshwater, and oil systems. Its angled body design facilitates efficient flow and compact installation, ensuring reliability and system integrity in tight spaces.
Standards & Compliance
- JIS Standards
- F7352F7410
Materials of Construction
- Body Material
- BC6 Bronze
- Bonnet Material
- BC6 Bronze
- Disc Material
- BC6 Bronze
- Stem Material
- C3771BD or BE
- Handwheel Material
- FC200
Technical Details
Suitable Media
- Seawater
- Freshwater
- Oil systems
- Valve Type
- Angle Check Valve
