Low Noise Diesel Generator Set
This low noise diesel generator set is designed for reliable power generation with reduced noise levels. It features a robust diesel engine coupled with a high-efficiency alternator, all enclosed in a sound-attenuated enclosure.
Technical Specifications
Overview
Silent Diesel Power Generation
This low noise diesel generator set is engineered for reliable power generation in sensitive environments, including residential areas, hospitals, and construction sites. Encased in a sound-attenuated enclosure, the unit combines a robust diesel engine with a high-efficiency alternator to minimize noise output. It features advanced operational safeguards such as automatic voltage regulation (AVR) and overload protection, ensuring consistent and safe power delivery while maintaining high fuel efficiency.
Key Features
- Operational Highlights
- Sound-attenuated enclosureAutomatic Voltage Regulation (AVR)Overload protectionWater-cooled engineHigh fuel efficiency
Technical Specifications
Performance Metrics
17 kVA
Minimum Power Output
413 kVA
Maximum Power Output
40 °C
Ambient Temperature Rating
Generator Model Specifications
| Model | Prime Power (kW) | Standby Power (kVA) | Fuel Cons. (L/h) |
|---|---|---|---|
| DG-FW17 | 12 | 17 | 2.27 |
| DG-FW40 | 28 | 39 | 3.86 |
| DG-FW70 | 50 | 69 | 3.86 |
| DG-FW110 | 80 | 110 | 6.55 |
| DG-FW220 | 160 | 220 | 7.7 |
| DG-FW413 | 300 | 413 | 12.53 |
Compliance & Standards
Certifications
ISO 9001:2015CEEPAGB/T2820ISO3046ISO8528
