Lithium-Ion Battery Charger 54.6V 4A for Electric Scooters
This lithium-ion battery charger is designed for electric motorcycles and scooters. It provides a 54.6V output at 4A, suitable for charging 13S (48V nominal) lithium-ion battery packs.
Technical Specifications
Overview
High-Efficiency Charging Solution
This 54.6V 4A charger is engineered for reliable and efficient power delivery to electric motorcycles, scooters, and e-bikes. Designed with a robust aluminium alloy casing, it ensures durability while providing stable charging for lithium-ion, LiFePO4, and lead-acid battery systems. The unit features integrated LED status indicators for real-time monitoring and is built to rigorous safety standards.
Technical Specifications
Output Specs
54.6 V
Output Voltage
4 A
Output Current
- Output Power
- 300 W
- Input Voltage Range
- 110-132VAC / 200-264VAC
- Compatible Battery Chemistries
- Li-ionLiFePO4Lead Acid
Physical Characteristics
- Dimensions
- 137 x 90 x 51 mm
- Net Weight
- 1 kg
- Casing Material
- Aluminium Alloy
Safety & Compliance
Certifications
CE
- Warranty
- 12 Months
Operational Information
LED Indicator Guide
| Status | Indicator |
|---|---|
| No Battery Connected | Green Flashing |
| Charging | Red Solid |
| Fully Charged | Green Solid |
| Error/Alarm | Red Flashing |
Applications
- Electric Motorcycle
- Electric Scooter
- E-bike
