Lithium Battery Charger 58.8V 4A for Electric Scooter Motorcycle
This lithium battery charger provides a 58.8V output, ideal for charging 14S 48V battery packs at a 4A charging current. It features LED indicators to display the charging status and ensure efficient charging of lithium-ion batteries in electric vehicles.
Technical Specifications
Overview
High-Efficiency Battery Charging Solution
This versatile 300W battery charger is engineered to provide reliable and efficient power for electric motorcycles, scooters, and e-bikes. Designed with a durable aluminium alloy housing, it supports various battery chemistries including Li-ion, LiFePO4, and lead-acid. With universal input voltage compatibility and a compact, lightweight design, it serves as an ideal charging solution for diverse international markets.
Technical Specifications
Key Power Metrics
300 W
Output Power
58.8 V
Output Voltage
4 A
Charging Current
- Input Voltage Range
- 110-132VAC / 200-264VAC
- Physical Dimensions
- 137 x 90 x 51 mm
- Net Weight
- 1 kg
- Housing Material
- Aluminium Alloy
Compatibility & Application
Suitable Applications
- Electric Motorcycle
- Electric Scooter
- E-bike
- Supported Battery Types
- Li-ionLiFePO4Lead Acid
Status Indicators
Charging Status Indicators
| Indicator Status | Meaning |
|---|---|
| Flashing Green | No battery connected |
| Steady Red | Charging in progress |
| Steady Green | Fully charged |
| Flashing Red | Error/Alarm |
Compliance & Support
Certifications
CE
- Warranty
- 12 Months
