Product Overview
Industrial Push Button & Indicator Series
The XDL21 series push buttons and signal lamps are designed for high-performance industrial control circuits. These components support AC voltages up to 660V and DC voltages up to 400V, making them ideal for signal control and interlocking applications. Constructed with high-grade anti-flam plastics and zinc alloy, these switches utilize special silver alloy contacts to ensure durability and resistance to electrical erosion.
Technical Specifications
Key Electrical Metrics
660 V
Rated Insulation Voltage (Ui)
10 A
Conventional Heating Current
6 kV
Withstanding Impulse Voltage (Uimp)
Environment & Compliance
| Feature | Rating/Detail |
|---|---|
| Protection Grade | IP65 |
| Operating Temperature | -5°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Pollution Grade | 3 |
Mechanical Durability
- Button mechanical life: 3,000,000 operations
- Emergency stop mechanical life: 300,000 operations
- Continuous working life: 100,000 hours
Certifications
Regulatory Compliance
CEISO 9001RoHSUL
