LED Elevator Position Indicator Push Button Switch
This LED push button switch indicates elevator position. It features a red handle and is designed for AC/DC 24V operation.
Technical Specifications
Overview
Industrial LED Indicator Push Button
This LED indicator push button switch is engineered for demanding industrial control circuits, supporting AC voltages up to 660V and DC voltages up to 400V. Featuring a durable combination of zinc alloy and high-grade anti-flam plastic, it ensures longevity and reliability in elevator position monitoring and signaling applications. Designed to meet stringent international electrical standards, it offers versatile protection options and high resistance to environmental stresses.
Technical Specifications
Rated Operating Capacity
660 V
Max AC Voltage
400 V
Max DC Voltage
6 kV
Impulse Voltage
- Compliance Standards
- IEC60947-5-1GB/T14048.1GB14048.5CEULISO9001RoHS
Environmental & Mechanical
Mechanical Durability
| Type | Cycles |
|---|---|
| Standard Pushbutton | 3,000,000 |
| Emergency Stop | 300,000 |
IP Rating
- Standard: IP40/IP54
- High Protection: IP65/IP66/IP67/IP68
- Ambient Temperature
- -5°C to +55°C (Operating), -25°C to +70°C (Storage)
Installation
- Fastening Torque
- 0.8 Nm
