Leaf Chain for Lifting and Hoisting
This high-quality leaf chain is designed for hoisting and lifting applications. It is suitable for use in forklifts, cranes, and other material handling equipment.
Technical Specifications
Product Overview
High-Performance Leaf Chains
Our range of leaf chains is engineered for demanding industrial environments, including lifting operations, automated warehousing, and heavy machinery. These chains are designed for strength and reliability, utilizing high-quality materials to ensure safe and efficient performance in applications ranging from forklifts to drill rigs. Available in multiple series, these chains are built to meet international standards for durability and load-bearing capacity.
Technical Standards
- Compliance Standards
- ANSI B29.9ISO 4347DIN 8152NFE 26107
Series Specifications
Available Series
- AL Series (Lightweight, ANSI B29.9)
- LL Series (European standard, ISO/DIN/NFE)
- BL Series (Heavy-duty, reinforced)
Series Comparison
| Series | Application Focus |
|---|---|
| AL | Light load lifting, machine tools |
| LL | Light load lifting, machine tools |
| BL | Heavy-duty, high-load applications |
Design Features
BL Series Engineering
The BL series features link plates that are thicker and larger in contour compared to the AL series of the same pitch. These plates match the thickness of the next larger pitch size in ANSI roller chains, and the pins are designed with the same diameter as those of the next larger pitch, providing superior load-bearing capability.
