Large Solar Collector for Space Heating
This high-capacity solar collector is designed for space heating applications. The robust unit efficiently captures solar energy and converts it into heat, making it suitable for integration into heating systems.
Technical Specifications
Product Overview
High-Efficiency Solar Heating Solution
This large-scale solar collector is engineered for high-capacity space heating, offering an impressive instantaneous efficiency intercept of 0.8. Designed specifically for performance in cold climates, it maintains high efficiency even with significant temperature differentials. Its monolithic design simplifies installation while maximizing energy absorption for residential and commercial applications.
Performance Metrics
Efficiency Ratings
0.8
Efficiency Intercept
66.1 %
Measured Efficiency
3.3 W/(m²*K)
Heat Loss Coefficient
Technical Specifications
Operating Temperatures
| Parameter | Temperature |
|---|---|
| Inlet Temperature | 30 °C |
| Outlet Temperature | 90 °C |
- Single Unit Area
- 10 m²
Design Features
Heat Retention Design
- Double cover plate for reduced heat loss
- Super thick insulation layer
- Reduced relative surface area per unit
- Monolithic array formation to eliminate small connections
Durability & Maintenance
- Environmental Resistance
- Severe Cold ResistantSnow MeltingFrost ResistantMaintenance-Free
Installation
Installation Advantages
Fast AssemblyReliable SealingModular Array
