Large Forging Hydraulic Press (800-3150 tons)
This large forging hydraulic press is used for free forging processes on metal materials. It can perform upsetting, punching, reaming, cutting, bending, and drawing operations, and can be equipped with special devices for ring blank hole systems and punching.
Technical Specifications
Overview
High-Performance Forging Hydraulic Press
The Y13 series large forging hydraulic press is engineered for heavy-duty metal forming processes, including upsetting, punching, bending, and drawing. Featuring a robust hydraulic system with multi-level overload and temperature protection, this equipment ensures operator safety and consistent performance. Advanced PLC control and a high-efficiency charging valve system minimize auxiliary time, significantly improving forging efficiency and overall production throughput.
Key Features
Safety & Protection
Overload ProtectionOil Temperature AlarmOil Level AlarmPLC ControlCooling Circulatory System
Performance Metrics
45 mm/s
Working Speed
25 MPa
System Pressure
50 T
Max Ingot Capacity
- Forging Applications
- UpsettingPunchingHorse Bar ReamerBendingDrawing OutCutting
Technical Parameters
Technical Specifications Overview
| Parameter | 800t | 1600t | 3150t |
|---|---|---|---|
| Nominal Pressure (MN) | 8 | 16 | 31.5 |
| System Pressure (MPa) | 25 | 25 | 25 |
| Slide Stroke (mm) | 1,000 | 1,400 | 1,900 |
| Working Speed (mm/s) | 45 | 45 | 45 |
| Motor Power (kW) | 330 | 990 | 1,650 |
