Technical Specifications
Overview
High-Performance Insulated Power Cable
This insulated power cable is engineered for reliable energy transmission in demanding industrial and infrastructure applications. Designed to meet international standards including IEC60502 and GB/T12706, it features robust construction with high-conductivity conductors and advanced insulation materials. Available in a wide range of voltage ratings, this cable provides essential durability and electrical safety for large-scale power engineering projects.
Technical Standards
Available Voltage Ratings (U0/U)
- 0.6/1 kV
- 1.8/3 kV
- 3.6/6 kV
- 6/10 kV
- 8.7/15 kV
- 12/20 kV
- 18/30 kV
- 21/35 kV
- 26/35 kV
- Compliance Standards
- IEC60502GB/T12706
Construction Details
Construction Components
| Component | Description |
|---|---|
| Conductor | Compacted or uncompacted copper or aluminium |
| Insulation | XLPE or PVC |
| Filler | Polypropylene filament with lapped binding tape |
| Armour | Galvanized steel wire (SWA) or steel tape (STA) |
| Sheath | Polyvinyl chloride (PVC) |
