Hydraulic Single Gypsy Mooring Winch
This 20KN electric mooring winch is designed for heavy-duty marine applications. It features a hydraulic motor and single gypsy wheel for efficient handling of mooring lines.
Technical Specifications
Product Overview
Heavy-Duty Mooring Solutions
This hydraulic single gypsy mooring winch is engineered for reliable performance in demanding maritime environments. Designed for secure and stable berthing, it features robust construction suitable for various vessel types, including ships, barges, and offshore platforms. The system integrates a high-performance hydraulic motor and gearbox to ensure precise control and efficient operation during mooring and anchoring tasks.
Certifications
- Authorized Classifications
- CCSLRGLRS
Technical Specifications
Performance Overview
18.5 kW
Min Power
45 kW
Max Power
Model Specifications
| Model | Power (kW) | Load (kN) | Speed (m/min) |
|---|---|---|---|
| LBHDY30 | 18.5 | 1,965 | 1,230 |
| DY40 | 18.5 | 1,965 | 1,230 |
| DY50 | 21.4 | 1,300 | 785 |
| DY60 | 30 | 2,295 | 1,350 |
| DY70 | 30 | 2,295 | 1,350 |
| DY80 | 45 | 2,540 | 1,450 |
