Technical Specifications
Overview
High-Performance Modular Conveyor Belt
This modular plastic conveyor belt is engineered for demanding industrial environments, including automotive manufacturing and food processing. It features a robust, maintenance-free design that offers exceptional durability and a long service life compared to traditional belts. With a high load capacity of up to 1.2 tons per square meter, it provides a reliable and efficient solution for conveying heavy components and materials.
Technical Specifications
Max Load Capacity
1.2 tons/sqm
Max Load
- Model Type
- HS-1800A-100
- Pitch
- 63.5 mm
- Thickness
- 25 mm
- Minimum Width
- 100 mm
- Open Area
- 0%
- Rod Diameter
- 10 mm
- Working Temperature
- -40°C to 260°C
Configuration & Materials
Available Colors
WhiteBlueGrayNatureDark-brown
Sprocket Specifications
| Feature | Details |
|---|---|
| Sprocket Size | 10T, 13T, 15T |
| Bore Type | Square & Round |
- Material Types
- PPPOMPEPA
Compliance & Features
Key Advantages
- Maintenance-free design
- Easy to clean
- Food defrosting capable
- Water buoyant
- Modular construction for easy repair
- Certifications
- FDAEU
Applications
Suitable Industries
- Automotive & Tire Manufacturing
- Food Processing (Meat, Poultry, Seafood, Bakery)
- Packaging & Printing
- Postal & Logistics
- Corrugated Cardboard
- Can & PET Manufacturing
