Horizontal Split Case Pump for Water Transfer
This horizontal split case pump is designed for high-capacity water transfer and circulation. The double-suction impeller ensures balanced hydraulic thrust and efficient operation.
Technical Specifications
Product Overview
Horizontal Split Case Pump for High-Capacity Water Transfer
This horizontal split case pump is engineered for high-efficiency water circulation and transfer across diverse industrial and municipal sectors. Its design features a double-suction impeller for balanced hydraulic thrust, ensuring reliable performance in demanding environments. The horizontally split casing provides exceptional maintenance accessibility, allowing for the inspection of internal components without the need to disturb existing piping systems.
Operational Metrics
Key Performance Indicators
106,000 USGPM
Max Capacity
760 feet
Max Head
200 °F
Max Temperature
Available Operating Speeds
- 2900/1450/980/740/580 rpm
- 3500/1750/1180/890/710 rpm
Construction Materials
Material Composition Table
| Component | Available Materials |
|---|---|
| Casing | Cast iron, Ductile cast iron, Stainless steel, Duplex stainless steel |
| Impeller | Cast iron, Ductile cast iron, Stainless steel, Duplex stainless steel, Bronze |
| Shaft | Stainless steel |
| Wear Ring | Cast iron, Ductile cast iron, Stainless steel, Bronze |
Applications
- Primary Applications
- Cooling waterWater supply/distributionFire protectionMetal manufacturingIrrigationGeneral industrial services
