High-Efficiency Solar Panel
This high-efficiency solar panel is designed for energy conversion. It features a robust construction with multiple solar cells arranged in a grid pattern, ensuring optimal sunlight capture.
Technical Specifications
Product Overview
High-Efficiency Monocrystalline Module
This monocrystalline solar module offers high conversion efficiency and robust mechanical stability for grid-connected systems. Engineered for durability, it features high-strength aluminum frames and is rigorously tested to withstand significant wind and snow loads. Each unit undergoes strict quality control to ensure defect-free performance and reliable long-term power output.
Performance Metrics
Featured Performance
17.8 %
Module Conversion Efficiency
290 W
Maximum Power (STC)
39.6 V
Open Circuit Voltage
9.27 A
Short Circuit Current
Physical Specifications
Dimensions and Weight
| Attribute | Value |
|---|---|
| Module Dimensions | 1640 x 992 x 35 mm |
| Weight | 19.0 kg |
| Cell Size | 156.75 x 156.75 mm |
| Cell Configuration | 60 (6x10) |
Certifications and Warranty
- Warranties and Standards
- ISO 9001 Certified10-year Product Warranty25-year Linear Power Warranty
Environmental Durability
Load Resistance
- Wind Load Resistance: 2400 Pa
- Snow Load Resistance: 5400 Pa
- Operating Temperature Range: -40 to +85°C
