High-Efficiency Solar Panel
This high-efficiency solar panel provides high power output and excellent weak light performance. It is designed to withstand harsh environments and has a lower operating temperature.
Technical Specifications
Overview
High-Efficiency Monocrystalline Module
This high-performance solar module series offers a power output range from 395W to 415W, engineered for superior energy conversion. Featuring advanced monocrystalline silicon technology, the panels achieve efficiencies up to 20.63%. Built for resilience in commercial and industrial environments, they are designed to withstand challenging weather conditions while maintaining reliable power output.
Electrical Performance
Performance Comparison
| Model | Pmax | Efficiency |
|---|---|---|
| 395M-72H | 395 | 19.63% |
| 400M-72H | 400 | 19.88% |
| 405M-72H | 405 | 20.13% |
| 410M-72H | 410 | 20.38% |
| 415M-72H | 415 | 20.63% |
Key Technical Specs
1,500 VDC
Max System Voltage
20 A
Max Series Fuse
3 %
Max Power Tolerance
Operating Environment
Temperature Coefficients
- Pmax: -0.37%/°C
- Voc: -0.29%/°C
- Isc: 0.048%/°C
- Operating Temperature
- -40°C to +85°C
