Helical Suspension Clamp for OPGW Fiber Optic Cables
Aluminum alloy suspension clamp designed for OPGW fiber optic cable. It provides a secure and reliable suspension point, minimizing stress and vibration.
Technical Specifications
Product Overview
Superior Cable Protection
This helical suspension clamp is engineered specifically for OPGW fiber optic cables, ensuring optimal cable and fiber protection at support points on transmission towers. The system utilizes structural reinforcing rods, outer rods, housing, and resilient inserts to effectively distribute loads and reduce compression, clamping, and bending stresses. Designed to withstand harsh environmental conditions, it minimizes negative cable motion, including aeolian vibration, galloping, and wind sway, ensuring long-term operational integrity.
Key Features
- Performance Benefits
- Vibration DampingStress ReductionCorrosion ResistantEasy InstallationGalvanized Steel Construction
Technical Specifications
Compatibility & Dimensions
| Catalog Number | Diameter Range (mm) | Color Code |
|---|---|---|
| OCL 0960 | 8.9-9.6 | Blue |
| OCL 1010 | 9.7-10.1 | Green |
| OCL 1060 | 10.2-10.6 | Yellow |
| OCL 1110 | 10.7-11.1 | Black |
| OCL 1160 | 11.2-11.6 | White |
| OCL 1170 | 11.7-11.7 | Purple |
| OCL 1210 | 11.8-12.0 | Purple |
