Gear Head Metal Lathe
This gear head lathe is designed for precision turning, facing, threading, and drilling. It features precision ground and hardened bed ways and a spindle supported with precision roller bearings.
Technical Specifications
Overview
Precision Gear Head Metal Lathe
This precision gear head metal lathe is designed for versatile metalworking tasks including turning, facing, threading, and drilling. Featuring a robust cast iron construction, it ensures excellent stability and vibration dampening during operation. The geared headstock provides multiple spindle speeds, making it suitable for a wide range of materials and cutting conditions, while the precision ground and hardened bed ways guarantee long-term accuracy for both professional and hobbyist machinists.
Key Features
- Core Capabilities
- Precision Ground Bed WaysPrecision Roller BearingsHardened Steel GearsLead Screw ThreadingAutomatic Feed Mechanism
Performance Metrics
Main Motor Power
1.5 HP
Power
1.1 kW
Power
- Spindle Speed Range
- 75 - 1400 r/min (Standard) / 60 - 2200 r/min (Variable)
Capacity & Dimensions
Swing Capacities
| Location | Diameter |
|---|---|
| Over Bed | 300mm (12") |
| Over Cross Slide | 178mm (7") |
| In Gap | 430mm (17") |
Travel Distances
- Saddle Longitudinal Travel: 600/800mm
- Cross Slide Travel: 160mm
- Top Slide Travel: 85mm
- Quill Travel: 95mm
Technical Specs
Threading Range
- Metric Threads: 0.4-7mm
- Inch Threads: 4-56 T.P.I
Spindle Specifications
- Bore Diameter: 38mm (1-1/2")
- Bore Taper: MT NO. 5
Physical Attributes
Physical Specs
- Overall Dimensions: 160 x 73 x 127cm
- Net Weight: 480kg
Electrical Configuration
380V/415V115V/230V110V/200V50Hz/60Hz
