Technical Specifications
Product Overview
High-Performance G80 Rotary Safety Hook
This G80 European rotary safety hook is a professional-grade lifting component engineered for demanding industrial and agricultural applications. Constructed from high-strength, heat-treated alloy steel, it offers an exceptional strength-to-weight ratio for reliable rigging operations. The integrated 360-degree swivel mechanism prevents rope or chain twisting, while the heavy-duty safety latch ensures secure load attachment, minimizing the risk of disengagement.
- Key Features
- Grade 80 Alloy Steel360-Degree SwivelCorrosion-Resistant FinishSafety Latch IncludedHeat-Treated
Technical Specifications
Technical Parameters Table
| Size | Weight (kg) | W.L.L (t) | B.L.L |
|---|---|---|---|
| 6-8 | 0.7 | 1.2 | 4.8 |
| 7/8-8 | 1.21 | 2 | 8 |
| 10-8 | 2 | 3.2 | 12.8 |
| 13-8 | 3.5 | 5.3 | 21.2 |
| 16-8 | 7.1 | 8 | 32 |
| 18/20-8 | 12 | 12.5 | 50 |
Compliance & Certification
Certifications
CE CompliantGrade 80 Standard
