Full Electric Injection Molding Machine
This full electric injection molding machine offers precision, high-speed operation, and energy-saving capabilities. It is suitable for use in electronics, communication, optics, medical treatment, food, and consumable goods industries.
Technical Specifications
Overview
High-Performance Electric Molding
This full electric injection molding machine is engineered for precision, high-speed operation, and superior energy efficiency. Designed with advanced servo control technology, it offers consistent performance suitable for demanding applications in electronics, communication, optics, and medical device manufacturing. Its robust construction and intelligent control systems provide a reliable solution for producing high-quality plastic components with tight tolerances.
- Ideal Applications
- ElectronicsCommunicationOpticsMedical TreatmentFood PackagingConsumable Goods
Injection Unit
Injection Performance
| Metric | Range |
|---|---|
| Screw Diameter | 28 - 45 mm |
| Injection Capacity | 77 - 254 cm³ |
| Injection Weight (PS) | 73 - 242 g |
| Max Injection Pressure | 166 - 287 Mpa |
| Max Injection Rate | 185 - 477 cm³/s |
| Plasticizing Capacity | 41 - 143 Kg/h |
- Max Injection Speed
- 300 mm/s
Clamping Unit
Clamping Force
130 ton
Clamping Force
Clamping Specifications
- Drive Travel: 400 mm
- Min Mould Thickness: 200 mm
- Max Mould Thickness: 450 mm
- Ejecting Force: 30 kN
- Ejection Stroke: 100 mm
Physical Dimensions
- Overall Dimensions
- 5.03m x 1.4m x 2.3m
- Machine Weight
- 6.8t7.1t7.4t
- Number of Thimbles
- 5
