Flexible Shaft Vibrator 6-20mm
Flexible shaft vibrators are available in diameters ranging from 6mm to 20mm. They are constructed from high-carbon steel for tensile strength and are suitable for automobile and machinery controls.
Technical Specifications
Product Overview
Flexible Shaft Vibrators
These high-quality flexible shafts are engineered for reliable power transmission in demanding industrial environments, including rubber processing and construction machinery. Constructed from durable high-carbon steel, they provide excellent tensile strength and flexibility for efficient vibration transfer. With a modular multi-layer design, they offer consistent performance and longevity for various compacting and vibration applications.
Technical Specifications
Operational Data
| Diameter (mm) | Tolerance (mm) | Layers | Torsion (10N.cm) | Weight (kg/100m) |
|---|---|---|---|---|
| 6.0 | 4/5/7 | 5.8 | 16.2 | |
| 6.5 | +0.00 | 4/5/7 | 6.2 | 18.7 |
| 8.0 | -0.10 | 4/5/7 | 10.0 | 28.8 |
- Material Grade
- 60# High-carbon steel70# High-carbon steel
Construction
Internal Structure
- Core vibrator (center rod)
- Five-layer reinforced winding design
