Engler Viscometer
The Engler Viscometer determines the ratio between the time used by a liquid flowing out of the device under specific conditions and distilled water at 20 ℃. This ratio represents the liquid's Engler viscosity.
Technical Specifications
Product Overview
Precision Viscosity Measurement
The Engler Viscometer is a specialized laboratory instrument engineered for the precise measurement of fluid viscosity, particularly for petroleum products and viscous materials. It operates by measuring the specific time required for a defined volume of fluid to flow through a calibrated orifice under strictly controlled temperature conditions. Designed for quality control and research, this device features robust stainless steel construction, advanced temperature regulation, and digital timing for reliable, repeatable performance.
Technical Specifications
Temperature Measurement Range
0 ℃
Min
100 ℃
Max
- Temperature Control Accuracy
- 0.1 ℃
- Heating Power
- 700 W
- Total Power Consumption
- 800 W
- Timing Mode
- LED timer
- Maximum Time Measurement
- 999 s
- Standard Water Value
- 51±1 s
Operating Environment
Operating Environment
| Parameter | Range |
|---|---|
| Ambient Temperature | -10℃ to +40℃ |
| Relative Humidity | ≤85% |
Power Requirements
- Power Supply
- AC 220 V±10%, 50 Hz
Design & Components
Measuring Flask Specifications
- Standard: 200±0.2 ml
- Asphalt Sample: 50±0.2 ml
- Construction Materials
- Stainless Steel Inner Container
- Thermometer Standard
- GB/T514
