Electric Cargo Tricycle
This electric cargo tricycle is a versatile solution for hauling goods, featuring a robust frame and spacious cargo bed. The efficient electric motor ensures quiet and emission-free operation.
Technical Specifications
Overview
Versatile Electric Cargo Solution
This electric cargo tricycle is engineered for efficient, eco-friendly goods transportation in both urban and industrial environments. Featuring a robust frame and a powerful 1000W motor, it offers reliable performance for heavy-duty tasks with minimal maintenance. The vehicle is equipped with advanced safety features, including EEC-certified lighting and linkage braking, ensuring operational confidence for professional use.
Performance
Power & Performance
1,000 W
Rated Power
2,300 W
Peak Power
26 km/h
Max Speed
50 km
Range
- Battery & Charging
- 60V/45Ah maintenance-free battery; 8-10 hours charging time
Dimensions & Capacity
Size Specifications
| Dimension | Value |
|---|---|
| Overall Size | 2895 x 1050 x 1320 mm |
| Cargo Box Size | 1400 x 1050 x 280 mm |
| Min. Ground Clearance | 150 mm |
| Min. Turning Radius | 6500 mm |
Weight & Load
280 kg
Curb Weight
480 kg
Rated Gross Weight
580 kg
Max. Designed Gross Weight
Technical Details
Mechanical & Drivetrain
- Motor: DC/square wave/magnetic steel height 50H
- Transmitting Mode: Gear transmitted
- Controller: 18 tubes controller (Max Current 45A)
- Rear Axle: Taper/ratio high speed 8.22:1, low speed 22:1
- Suspension: Duplex hydraulic front, Leaf spring rear
- Safety & Certification
- EEC Certified LightsLinkage Braking SystemMechanical Drum BrakesOff-seat AlarmDust-protected Shock Absorbers
Logistics
- Shipping Information
- 40HQ Container Packing: 60 sets (CKD)
