Dual Table Conformal Coating Machine
This machine features a dual table design to enable continuous operation and improve production efficiency. It is designed for precise and automated application of conformal coatings on electronic components.
Technical Specifications
Overview
Dual Station Precision Dispensing System
This desktop industrial dispensing robot features a dual-station design, allowing for uninterrupted operation and rapid changeover of parts. It is engineered for high-precision applications including conformal coating, form-in-place gaskets, potting, and sealing. With advanced motion control and user-friendly graphical programming software, this system offers a versatile and efficient solution for small to medium-sized production environments.
Technical Specifications
Maximum Load Capacity
15 kg
XY Axis
6 kg
Z Axis
- Working Range (X/Y1/Y2/Z)
- 500 x 300 x 300 x 100 mm
- Repetitiveness
- ±0.01 mm/Axis
- Operating Speed
- XY: 0.1-800 mm/s | Z: 350 mm/s
System Capabilities
- Supported Dispensing Patterns
- DotsLinePottingFillingEncapsulationSealingCoatingJetting
- Supported File Formats
- NCAIDXFJPGBMP
- Program Memory Capacity
- 999
Physical & Environmental
Operating Environment
| Parameter | Range |
|---|---|
| Temperature | 0-40°C |
| Relative Humidity | 20-90% (non-condensing) |
- Dimensions (W x D x H)
- 84.5 x 75 x 78 cm
- Packed Weight
- 57 kg
Compliance & Certification
Certifications
CE Approved
