Double Bevel Cutting Edge for Earthmoving Equipment
This is a double bevel cutting edge designed for ground engaging tools. It is manufactured from hardened steel to provide increased wear resistance and extended service life.
Technical Specifications
Product Overview
High-Performance Cutting Edges
These double bevel cutting edges are engineered for heavy-duty earthmoving, mining, and construction equipment. Manufactured for superior wear resistance, they provide optimal cutting performance and durability in the most demanding environments. Our range includes precision-engineered parts suitable for a wide variety of machinery, ensuring reliable operation for grading, scraping, and leveling tasks.
Compatibility & Applications
Product Categories
Bucket TeethTooth AdaptersRipper ShanksRipper PointsCutting EdgesEnd BitsGrader BladesSegmentsWear Resistant Parts
- Compatible Equipment Types
- ExcavatorsBackhoe LoadersBulldozersCompactorsLoadersScrapers
Technical Specifications
Part Dimensions & Specifications
| Part Number | Dimensions (L x W x T) | Hole Size |
|---|---|---|
| 6Y5540 | 803 x 330 x 30 mm | 1" |
| 4T6659 | 1052 x 203 x 19 mm | 3/4" |
| 4T3009 | 1520 x 203 x 19 mm | 3/4" |
| 9W1878 | 1227 x 254 x 19 mm | 3/4" |
| 9W8215 | 1130 x 203 x 19 mm | 5/8" |
| 1U0593 | 1319 x 360 x 30 mm | 1-1/4" |
| 1U0762 | 1406 x 406 x 35 mm | 1-1/4" |
| 1U0292 | 1161 x 280 x 25 mm | 1" |
| 7T6936 | 908 x 280 x 25 mm | 7/8" |
