Digital Fabric Air Permeability Tester
The Air Permeability Tester determines fabric resistance to air passage under constant pressure. It automatically calculates air permeability rapidly.
Technical Specifications
Product Overview
Precision Air Permeability Testing
This digital fabric air permeability tester provides accurate and swift measurements of air resistance for various textiles, including woven, knitted, and nonwoven materials. Designed for both quality control and research, the system features automated testing, interchangeable test heads for multi-size compatibility, and advanced data connectivity. It is an essential instrument for assessing functional textiles, weather-proof materials, and filtration products.
Technical Specifications
- Test Pressure
- 3000 Pa
- Flow Test Range
- 0.3-12000 mm/s
- Sample Thickness
- 10 mm
- Available Test Areas
- 5cm²20cm²25cm²38cm²50cm²100cm²
Features
Smart Features
- Automatic identification of test head size
- Electromagnetic induction clamping system
- WIFI-enabled remote monitoring
- Automated data analysis and recording
Standards Compliance
- Industry Standards
- GB/T 5453ISO 9237ASTM D737DIN 53887JIS L1096TAPPI T 251EDANA 140.2BS 5636ASTM D3574
Physical Attributes
Dimensions & Weight
900 mm
Length
590 mm
Width
1,000 mm
Height
80 kg
Weight
