Diesel Generator Set for Industrial Power
This diesel generator set provides a reliable power source for various applications. It features a robust engine, durable enclosure, and advanced control panel for efficient operation and monitoring.
Technical Specifications
Overview
Industrial Diesel Generator Sets
These industrial-grade diesel generator sets are engineered for reliable, stable, and efficient power generation across a wide range of applications. Available in configurations from 9KVA to 2500KVA, these units feature high-quality steel construction and advanced sound-insulation technology for quiet operation. Designed for durability and ease of maintenance, they include integrated cooling systems, robust control panels, and flexible installation options such as open, silent, trailer, and container types.
Performance
Power Output Range
2 KVA
Minimum Prime Power
2,500 KVA
Maximum Prime Power
- Operating Frequency
- 50Hz @ 1500rpm60Hz @ 1800rpm
Technical Specifications
Rated Voltage Options
- 120V/240V
- 220V/380V
- 230V/400V
- 254V/440V
Alternator Details
| Feature | Specification |
|---|---|
| Excitation Type | Brushless, self-excited or PMG |
| Insulation Class | Class H |
| Protection Class | IP21 - IP23 |
| Voltage Regulation | AVR 1% |
Design & Enclosure
Available Enclosure Types
OpenSilentContainerTrailer
- Canopy Steel Thickness
- 10 mm
Compliance & Environment
Operating Environment Limits
- Altitude: ≤1000 meters
- Ambient Temp: ≤40°C
- Relative Humidity: ≤90%
- Manufacturing Standards
- GB/T2820ISO8528IEC34CEEPA Tier4GB755BS 5000VDE 0530NEMA MG1-22
Warranty
- Warranty Terms
- 1 year or 1000 hours (whichever comes first) from ex-factory date.
