Diesel Generator Set 63kVA-750kVA
This generator set is equipped with a Korea Doosan engine and meets high emission standards EU II-IIIA. It offers a power range of 63kVA-750kVA, suitable for home, factory, and power station needs.
Technical Specifications
Overview
High-Performance Diesel Power Solutions
This versatile range of diesel generator sets offers reliable power from 63kVA to 750kVA, suitable for residential, industrial, and power station applications. Engineered for efficiency and durability, these units feature advanced vibration isolation and integrated wiring for stable operation. With high emission standards and multiple configuration options, they provide a robust solution for both prime and standby power needs.
Performance Metrics
Power Output Range
63 kVA
Minimum Power
750 kVA
Maximum Power
Emission Standard
EU IIEU IIIA
Engine & Alternator
- Engine Origin
- South Korea
- Excitation System
- Self-excited (PMG optional)
- Radiator Rating
- 40 °C
Control & Safety
- Control System
- DSE7320 with AMF function
- Safety Equipment
- Lockable Battery IsolatorCircuit BreakerIndustrial MufflerSafety LabelsProtection Functions
Physical Construction
Chassis Features
- Steel base frame
- Top lifting points
- Forklift holes
- Vibration isolators
- Integrated fuel tank drainage
Operational Capacity
- Standard Running Time
- At least 8 hours (Standard for units below 500kVA)
- Available Voltages
- 127V/220V132V/230V220V/380V254V/440V266V/460V277V/488V
Customization Options
Optional Add-ons
- Auto Transfer Switch (ATS)
- Paralleling Switchgear
- Battery Charger
- Water Jacket Preheater
- Oil Heater
- Double Air Cleaner
Technical Specifications
50Hz Model Specifications
| Model | Prime (kVA) | Standby (kVA) | Open Weight (kg) |
|---|---|---|---|
| LGDO-165 | 150 | 165 | 1,700 |
| LGDO-250 | 225 | 250 | 2,100 |
| LGDO-500 | 453 | 500 | 4,000 |
| LGDO-825 | 750 | 825 | 4,800 |
