Technical Specifications
Overview
Reliable Power Generation
This diesel generator set is engineered for consistent and stable power performance in industrial, commercial, and residential backup applications. Featuring a robust 3-cylinder engine and an advanced control interface, it ensures reliable operation with essential monitoring for voltage, frequency, and engine health. Built on a vibration-dampened base frame, this unit combines durability with efficiency to meet demanding power requirements.
Power Performance
Standby Output Power
35 KVA
Standby Power
28 KW
Standby Power
Nominal Output Power
31 KVA
Nominal Power
25 KW
Nominal Power
Engine Specifications
Engine Configuration
| Parameter | Value |
|---|---|
| Cylinders | 3 |
| Bore | 105 mm |
| Stroke | 120 mm |
| Volume | 3.12 L |
- Engine Model
- D226B-3
- Speed Adjustor
- Mechanical
Operational Metrics
Fluid Capacities
- Lubrication Oil: 7.25 L
- Cooling Water: 17 L
- Oil Consumption
- 6 L/H
- Exhaust Gas Max Temperature
- 470 °C
Physical Dimensions
- Dimensions (L×W×H)
- 1800 × 980 × 1290 mm
- Weight
- 710 Kg
Electrical Systems
- Output Voltage
- 400/230 V
- Starting Cell Voltage
- 24 V
