Diesel Engine for Small Generators
This diesel engine is designed for small power generators. It features efficient fuel consumption and durable construction.
Technical Specifications
Product Overview
Reliable Diesel Engines for Power Generation
These small-scale diesel engines are specifically engineered for integration into small powered generators, providing a robust and efficient power source for industrial and commercial applications. Featuring a four-stroke design and naturally aspirated intake, they offer dependable performance and simplified maintenance. With multiple models available, these engines cater to a variety of power requirements while maintaining a compact footprint for easy installation.
Technical Specifications
Engine Model Comparison
| Model | Bore & Stroke (mm) | Displacement (L) | Cylinder Liner |
|---|---|---|---|
| QC380D | 80*90 | 1.357 | Wet |
| QC385D | 85*90 | 1.532 | Dry |
| QC480D | 80*90 | 1.809 | Dry |
| N485D | 85*95 | 5.516 | Wet |
| QC490D | 90*105 | 2.67 | Wet |
Performance Features
Engine Cycle
Four-Stroke
- Intake System
- Naturally aspirated
Cooling & Maintenance
Maintenance Requirements
- Replace oil filter every 10,000 km
- Clean and inspect threads during filter changes
- Tighten filter 1/2 to 3/4 turn after gasket contacts base
- Regularly check for fluid leaks
- Cooling System
- Radiator cooling system with cooling fan
Components
- Included Components
- Fuel Injection SystemAir Intake FilterFuel PumpOil FilterRadiator
