DC Inverter TIG/MMA Welding Machine
This DC inverter TIG/MMA welding machine is designed for TIG and MMA welding processes. It features advanced inverter technology and a 2-in-1 multifunction design, allowing it to weld different kinds of metallic materials with ease.
Technical Specifications
Overview
Professional DC Inverter TIG/MMA Welder
This versatile DC inverter welding machine supports both TIG and MMA welding processes, making it a flexible solution for various metalworking tasks. Engineered for efficiency, it features a high 85% efficiency rating and a power factor of 0.93. With its compact design and lightweight 9kg build, it offers excellent portability without compromising on performance for professional workshop environments.
Performance Metrics
Output Current Range
10 A
Min Current
200 A
Max Current
- Duty Cycle
- 60 %
Electrical Specifications
- Input Power Voltage
- AC220V±15%
- Input Voltage Frequency
- 60 HZ
- Rated Input Power Capacity
- 4.6 KVA
- Rated Input Current
- 20.7 A
- No-Load Voltage
- 56 V
- Power Factor
- 0.93
Technical Details
- Efficiency
- 85 %
- Post-Gas Time
- 2 S
- Arc-Striking
- HF
Physical Characteristics
- Dimensions
- 403×153×302mm
- Weight
- 9 KG
Safety and Ratings
Protection Class
IP21
- Insulation Class
- B
