CQ6236D Bench Lathe
The CQ6236D bench lathe is designed for precision turning operations, featuring complete threading capabilities for metric, imperial, diametric, and module threads. Head stock gears are made of high-quality steel, ground and hardened for durability.
Technical Specifications
Overview
Precision Engineering for Versatile Turning
The CQ6236D Bench Lathe is a professional-grade metalworking machine designed for turning, facing, threading, and drilling operations. Engineered for stability and vibration damping, it features a robust cast iron bed that ensures accurate machining for small to medium-sized workshops. With a wide range of spindle speeds and threading capabilities, this versatile lathe provides the precision and control required for diverse metalworking tasks.
Capacity & Dimensions
Working Capacity Comparison
| Specification | CQ6232D | CQ6236D |
|---|---|---|
| Swing over bed | 330mm | 360mm |
| Swing over cross slide | 198mm | 224mm |
| Swing in gap diameter | 476mm | 502mm |
| Center height | 166mm | 179mm |
Spindle & Headstock
Spindle Specifications
- Spindle bore: 38mm or 51mm
- Spindle nose: D1-4 or D1-5
- Spindle taper: No. 5 Morse
- Speed range: 70-2000 r/min
- Number of speeds: 8
Threading & Feeds
Threading Capabilities
- Imperial threads: 42 Nos. (4-112 T.P.I)
- Metric threads: 44 Nos. (0.1-7mm)
- Diametral pitches: 25 Nos. (16-112 DP)
- Module pitches: 34 Nos. (0.1-1.75 MP)
Electrical & Power
Power Ratings
1.5 kW
Main Motor Power
40 W
Coolant Pump Power
Tailstock
Tailstock Specifications
- Quill diameter: 32mm or 42mm
- Quill travel: 100mm
- Quill taper: No. 3 Morse
Logistics
Shipping Specifications
| Model Length | Packing Size (cm) | Net/Gross Weight (kg) |
|---|---|---|
| 750mm | 168x76x158 | 510/630 |
| 1000mm | 193x76x153 | 540/645 |
