Conveyor Dishwasher
This conveyor dishwasher is designed for high-volume dishwashing in commercial settings. It automatically moves dishes through washing, rinsing, and drying stages for efficient and consistent cleaning.
Technical Specifications
Overview
High-Efficiency Conveyor Dishwasher
This automatic commercial dishwasher is engineered for high-volume environments such as restaurants and hotels. Featuring a robust stainless steel construction, it utilizes a continuous conveyor system to streamline washing, rinsing, and drying stages. Designed for professional kitchens, it balances high throughput with energy-efficient operation to reduce utility costs while maintaining strict hygiene standards.
Dimensions & Capacity
- Dimensions
- 5690 x 920 x 1900 mm
- Processing Capacity
- 3500 items/H
Power & Electrical
Total Power Consumption
68.48 kw
Total Power
Power Component Breakdown
| Component | Power |
|---|---|
| Rinse Pump | 0.37 kw |
| Frequency Conversion Heating | 8.5 kw x 3 |
| Transmission Motor | 0.75 kw |
| Drying Heating | 28.8 kw |
| Drying Fan | 2.2 kw x 2 |
| Booster Pump | 0.16 kw |
| Constant Temperature | 7 kw |
- Voltage
- 380V
Features
- Key Features
- Stainless Steel ConstructionAutomatic Conveyor SystemContinuous DryingAdjustable Wash ParametersWater Filtration System
