Technical Specifications
Product Overview
Continuous Microwave Vacuum Dryer (Model WZL-900)
The WZL-900 is a specialized belt microwave vacuum drying machine designed for high-viscosity, heat-sensitive materials such as traditional dipping creams, food products, and chemical compounds. By combining microwave energy with low-temperature vacuum technology, it enables rapid, continuous drying while preserving product quality and preventing oxidation. The system features advanced PLC and touchscreen controls for precise management of temperature and pressure, ensuring stable, intelligent operation.
Technical Specifications
- Microwave Frequency
- 2450 MHZ
- Total Output Power
- 40 kW
- Microwave Output Power
- 20 kW
- Drying Temperature Range
- 3–120°C (Adjustable)
Performance & Capacity
- Output Capacity
- 3–20 kg/h (Depends on material)
- Water Supply Quantity
- 0.5 cube/h
Electrical & Environmental
- Power Supply
- Three phases five wires, 380v+5%/-10%, 50Hz
- Operating Environment Temperature
- -5 to 40°C
Physical Dimensions
- External Dimensions
- 6600mm x 1680mm x 2500mm
Key Features
System Features
- Continuous drying process
- PLC and touchscreen control
- Precise temperature and pressure regulation
- Auto feed-in and feed-out transmission
- Low energy consumption
- Suitable for heat-sensitive materials
