Construction Hoist Elevator
This construction hoist elevator is designed for lifting materials and personnel on construction sites. It features a modular structure and advanced manufacturing technology to enhance adaptability and reliability, with a maximum lifting height of 300 meters.
Technical Specifications
Overview
Professional Construction Hoist Elevator
This construction hoist is engineered for efficient and safe vertical transportation of personnel and materials on demanding construction sites. It features a robust, patent-pending structural design with a buffered cage drive system for enhanced stability and operator comfort. Equipped with high-quality components and comprehensive safety devices, this elevator provides reliable performance for various project requirements, including specialized configurations for cooling towers.
Technical Specifications
Key Performance Metrics
2,000 kg
Max Rated Load
300 m
Max Lifting Height
60 m/min
Max Lifting Speed
Model Comparison
| Model | Configuration | Load (kg) | Passengers |
|---|---|---|---|
| SC200/200 | Standard | 2,000 | 16 |
| SC200/200BP | Frequency Conversion | 2,000 | 16 |
| SCD200/200 | Counterweight | 2,000 | 16 |
| SC100/100 | No Counterweight | 1,000 | 12 |
Cage Dimensions
- 3.0m x 1.3m x 2.2m (Standard)
- 3.2m x 1.5m x 2.4m (Optional)
Features & Safety
Structural Highlights
Patent-pending designReinforced guide rail (800mm)Ergonomic interiorPrecise assembly
- Safety Systems
- Buffered Cage DriveOverload ProtectionEmergency Stop MechanismReliable Control SystemDisc Brake Electric Motor
