Computer Controlled Torsion Testing Machine
This machine applies to the torsion test of metal or nonmetal materials and some parts. The load system is the computer-controlled AC servo control system.
Technical Specifications
Overview
Precision Torsion Testing
This microcomputer-controlled torsion testing machine is engineered for high-precision torsional performance testing of metal and non-metal materials. Utilizing an imported AC servo control system, it delivers accurate torque and angle measurements with dynamic real-time screen display. It is an essential tool for aviation, construction, and research laboratories requiring reliable material characterization.
Key Metrics
Performance Highlights
2,000 Nm
Max Torque Capacity
9,999.9 °
Torsional Angle Range
500 mm
Max Collet Distance
Technical Specifications
Model Specifications
| Feature | NJ-W500 | NJ-W1000 | NJ-W2000 |
|---|---|---|---|
| Max Test Torque | 500Nm | 1000Nm | 2000Nm |
| Torque Display Range | 10-500Nm | 20-1000Nm | 40-2000Nm |
Accuracy & Precision
- Relative Error of Torque Display: ±1%
- Repetitive Error of Torque Display: ±1%
- Relative Error of Torsional Angle Display: ±1%
Physical & Electrical
Physical Dimensions & Power
- Host Machine Dimensions: 1650x530x1000mm
- Weight: 600kg
- Power Supply: 220V±10%, 50Hz
Applications
- Suitable Industries
- Aviation & SpaceflightConstruction TradeTransportation TradeUniversity ResearchMaterial Science Labs
