CNC Lathe
This CNC lathe is designed for precision machining operations. It features a CNC control system for automated operation and precise control over machining parameters.
Technical Specifications
Overview
High-Precision CNC Lathe for Industrial Machining
The STL10 is a high-performance CNC lathe featuring a cast mono-block, 35° slant bed design for superior stability and accuracy. It is equipped with a high-speed bidirectional indexing turret and an automatic hydraulic tailstock that reduces setup time by up to 90% compared to manual alternatives. This versatile machine is ideal for a wide range of turning applications including facing, threading, and drilling in demanding B2B manufacturing environments.
Key Performance Metrics
Key Performance Metrics
10 inch
Chuck Size
3,000 rpm
Spindle Speed
500 mm
Max Swing Over Bed
18 kVA
Power Capacity
Capacity & Dimensions
- Max Swing Over Slide
- 300 mm
- Max Workpiece Length
- 750 mm (up to 1500 mm optional)
- Overall Dimensions
- 3350 x 2000 x 2350 mm
- Machine Weight
- 5850 kg
Spindle & Motor
- Spindle Bore Diameter
- 86 mm
- Spindle Nose Type
- A2-8
- Main Motor Power
- 11/15 kW
Axis & Turret
- Axis Travel (X/Z)
- X: 280 mm / Z: 750 mm
- X/Z Rapid Traverse
- 15/20 m/min
- Number of Tool Stations
- 8
- Tool Shank Size
- 25 x 25 mm
Tailstock
- Tailstock Type
- Automatic Hydraulic
- Tailstock Quill Taper
- MT5
- Tailstock Quill Travel
- 150 mm
Standard Features
Standard Features
- Hydraulic 3-Jaw Chuck
- 8-Station Bi-directional Turret
- Automatic Lubrication System
- Automatic Coolant System
- Hydraulic Tail Stock
- Handheld Electronic Hand Wheel
Construction
Machine Characteristics
Cast Mono-BlockTrue Align Slant BedLinear Motion GuidewaysErgonomic Control PanelCE Certified
Optional Configurations
- Available Options
- 12-Station TurretChip ConveyorTool SetterCollet ChucksCustom CNC Systems
