Cable Stranding and Armoring Machine
This machine is used for manufacturing wire without back-twist, including copper strand, aluminum strand and ACSR. It is also capable of stranding and compacting sector and round conductors.
Technical Specifications
Overview
High-Performance Cable Stranding and Armoring
This industrial-grade machine is engineered for the precise stranding and armoring of copper and aluminum wires. Featuring a hollow shaft integrated design and compact structure, it ensures high-speed operation with exceptional rigidity. The system is highly configurable, offering both mechanical transmission and frequency synchronization options to meet demanding cable manufacturing requirements.
Key Performance Metrics
Performance Highlights
50.2 m/min
Max Production Speed
168 r/min
Max Frame Rotation
1,600 mm
Capstan Wheel Dia.
Technical Specifications
Machine Parameters
| Parameter | Specification 400/12+18+24 | Specification 500/12+18+24 |
|---|---|---|
| Copper Wire Dia. (mm) | 1.5 - 5.0 | 1.5 - 5.0 |
| Aluminum Wire Dia. (mm) | 2.1 - 5.0 | 2.1 - 5.0 |
| Max OD of Stranding (mm) | 45 | 45 |
| Frame Rotation Speed (r/min) | 48 - 168 | 48 - 168 |
| Stranding Pitch (mm) | 40 - 750 | 40 - 750 |
| Production Speed (m/min) | 6.1 - 50.2 | 6.1 - 50.2 |
System Configuration
Included Components
- Center pay-off strand
- Stranding cartage
- Compact die stand
- Double draught wheels
- Take up and traverse device
- Mechanical transmission system
- Electrical control system
Construction Features
Design & Safety Features
- Hollow shaft integrated processing for compact structure
- Clamping thimble plate hand wheel for wire reel pressure
- Integrated machine locked safeguard for reel clamping
- Transmission shaft linked stranding cages for tighter assembly
- Optional frequency synchronization for cage driving
Operational Capacities
Take-up Reel Size
PN2000
- Compatible Materials
- CopperAluminumACSRCopper Screening
