Brushless Drilling and Milling Machine
This drilling and milling machine combines both functions in a single versatile machine tool. Its brushless motor ensures smooth, reliable performance and reduces the need for maintenance.
Technical Specifications
Overview
Versatile Precision Machining
This brushless drilling and milling machine is a robust tool designed for high-precision metalworking, combining drilling and milling capabilities into one efficient unit. Featuring a brushless motor, it delivers reliable, quiet performance with minimal maintenance requirements. Its heavy-duty construction and adjustable controls make it ideal for demanding tasks ranging from prototype development to small-batch production.
Performance
Key Performance Metrics
1.5 kW
Power Output
580 kg
Net Weight
120 mm
Spindle Stroke
- Max Drilling Capacity
- 40 mm
- Max End Milling Capacity
- 32 mm
- Max Face Milling Capacity
- 80 mm
- Spindle Speed Range
- 60-2500 rpm
Technical Specifications
- Table Size
- 800x240 mm
- Table Travel (X,Y)
- 560x230 mm
- Spindle Incline Angle
- ±90°
- Spindle Taper
- MT3MT4R8ISO30
Features
Included Accessories
- Drill Chuck 3-16/B16
- Drawbar
- Arbor MT2/B16-M10
- Digital Depth Ruler
- Spindle Cover with Micro Switch
- Toolbox & Tools
Compliance
CEIP20
