Technical Specifications
Overview
42mm Series High-Performance Brushless DC Motor
The 42mm Series Brushless DC Gear Motor is designed for high-performance motion control applications requiring energy efficiency and long service life. Featuring a permanent magnet construction and brushless commutation, it eliminates spark interference and reduces maintenance needs. This versatile motor is suitable for a wide range of industrial and domestic uses, including CNC machine tools, medical equipment, and home appliances.
Key Features
Core Advantages
- High power density and small moment of inertia
- Energy-saving permanent magnet rotor design
- Low noise operation without brush sparks
- Integrated protection: overvoltage, undervoltage, and overheating
- Compatible with various reducers (tower, worm gearbox)
Technical Specifications
Performance Metrics
8,000 RPM
Max Speed
105 W
Max Power
250 mN·m
Max Torque
Protection Rating
IP40 StandardIP65 OptionalWaterproof
- Voltage Options
- 24VDC36VDC
- Insulation Class
- Class B & Class F available
- Work Duty
- S1 (Continuous), S2, or S3
Product Variants
Model Specifications Table
| Model Number | Power (W) | Speed (RPM) | Torque (mN·m) | Length (mm) |
|---|---|---|---|---|
| 42BLB1B001204RN-01 | 13 | 2,000 | 63 | 41 |
| 42BLB0C006304RN-01 | 62 | 3,000 | 201 | 51 |
| 42BLB2B010804RN-01 | 104 | 8,000 | 125 | 61 |
| 42BLB4B010404RN-01 | 105 | 4,000 | 250 | 101 |
Applications
- Common Applications
- CNC Machine ToolsRoboticsHome AppliancesElectric BicyclesMedical EquipmentIndustrial Control
Certifications
Certifications
CCCCE
