Brass Boiler Drain Ball Valve
This brass boiler drain ball valve is designed for efficient boiler drainage. It features a ball valve mechanism for reliable shut-off and a threaded side outlet allows for convenient connection to drainage systems.
Technical Specifications
Product Overview
Professional Grade Boiler Drain Valve
This forged brass boiler drain ball valve is engineered for reliable performance in residential and commercial plumbing and heating systems. Featuring a durable ball mechanism for positive shut-off and manual operation, it is designed for efficient water drainage and system maintenance. With certifications including cUPC and NSF, it meets rigorous standards for safety and quality in potable water applications.
Technical Specifications
- Model Number
- 5220 / LF-5220
- Material Grade
- C37700C46500Forged Brass
- Port Size Range
- 1/2" - 3/4"
- Valve Structure
- Ball Valve
Compliance & Standards
Certifications
cUPCNSF61NSF372
Thread Compliance
- Hose threads: ANSI B1.20.7
- Pipe threads: ANSI B1.20.1
Operating Conditions
Performance Metrics
125 PSI
Max Pressure
250 °F
Max Temp
- Compatible Media
- WaterOilGas
Supply & Logistics
Shipping Information
| Detail | Value |
|---|---|
| Loading Ports | Shanghai / Ningbo |
| Lead Time | 35 Days after payment |
| Customization | OEM / Custom Packaging Available |
- Monthly Supply Capacity
- 500,000 Pieces
