Bolt-On Corner Adapter 3G4258 for J250 Series
This bolt-on corner adapter is a replacement part for J250 series equipment. The 3G4258 adapter is made from alloy steel.
Technical Specifications
Product Overview
Heavy-Duty Corner Adapter
This high-performance bolt-on corner adapter is engineered for demanding applications in loaders and excavators. Manufactured using precision casting methods with high-grade alloy steel, it provides exceptional durability and structural integrity. Designed for the J250 series, this component ensures reliable operation and is built to withstand rigorous working conditions.
Technical Specifications
- Part Number
- 3G4258
- Production Method
- Casting
- Material
- Alloy steel
Performance Metrics
Mechanical Properties
520 HB
Max Hardness
1,450 N/mm²
Min Tensile Strength
1,100 N/mm²
Min Yield Strength
15 J
Min Impact Energy
Compatibility
Compatible Machine Types
LoaderExcavator
Required Installation Hardware
| Component | Part Number |
|---|---|
| Matched Bolt | 4J9058 |
| Matched Nut | 8J2933 |
