Bevel Gear Operated Flat Bottom Valve
This pneumatic tank bottom angle valve is designed for the quick discharge of materials or samples from a reactor. It can be welded or flanged to a vessel for installation, commonly used for feeding vessels or draining pipelines.
Technical Specifications
Product Overview
Tank Bottom Angle Valve
This tank bottom angle valve is engineered for efficient material discharge from reactors, drains, or feed vessels. Its specialized flat bottom design eliminates dead space, ensuring seamless draining and preventing material accumulation. Built with a robust integrated structure and advanced sealing technology, it offers reliable performance for demanding industrial flow control.
Technical Specifications
Operating Types
- Pneumatic
- Manual
- Electric
- Size Range
- DN50 to DN350 (NPS2 to NPS14)
- Pressure Class
- Class 150 to Class 300
- Working Temperature
- 425 °C
- Flange Standards
- ASME B16.5GB/T9113
- Design Standard
- ASME B16.34
Construction & Materials
Available Outlet Angles
- 45°
- 50°
- 90°
- Body Materials
- Carbon SteelStainless Steel
- Sealing Surface Material
- Alloy (Cemented Carbide / Tungsten Carbide)
Applications
Industries Served
PetrochemicalAluminaSteelPolymerMiningPharmaceuticalFine ChemicalsMineral Processing
