Bellow Seal Globe Valve for Industrial Fluid Control
The Bellow Seal Globe Valve is designed for critical applications requiring zero stem leakage, incorporating a bellow seal that provides a hermetic barrier. Suitable for handling hazardous, toxic, or corrosive media, the valve ensures environmental protection and safety.
Technical Specifications
Overview
Bellow Seal Globe Valve
This bellow seal globe valve is engineered for critical fluid control applications, ensuring zero stem leakage through a hermetic bellow seal design. It is ideal for industries such as petroleum, chemical, pharmaceutical, and power generation where environmental safety and precise flow adjustment are paramount. Designed to handle aggressive media across a wide range of temperatures and pressures, this valve offers reliable performance and a long service life.
Performance Metrics
Pressure Rating
150 LBS
Min Class
1,500 LBS
Max Class
250 PN
Max PN
- Operating Temperature
- -29°C to 350°C
Technical Specifications
Material Options
WCBLCBWC6WC9C12C5CF8CF3CF3MCF8M
Functional Capabilities
- Fluid cutting
- Fluid switching
- Flow adjustment
- Parabolic plug for precise control
- Available Sizes
- 1/2" - 18" (DN12 - DN450)
- Design Standards
- API 600API 6DASME B16.10ASME B16.5API 598
