Technical Specifications

Product Overview

Precision Heat Resistance Testing

The Ball Pressure Test Apparatus is an essential tool for fire hazard testing, specifically designed to assess the heat resistance of non-metallic and solid electrical insulating materials. By simulating thermal stress conditions, this apparatus verifies the structural integrity of enclosures and external components in electrical appliances. It is a critical instrument for ensuring compliance with national and international safety standards.

Technical Specifications

Testing Mechanism

Spring-loaded force application
Controlled temperature heating
Indentation depth measurement
Post-cooling analysis

Suitable Materials

Non-metallic materialsSolid electrical insulationEnclosuresExternal components

Ball Diameter: 5 mm

Standards Compliance

Conforms To: IEC60238IEC60309IEC60320IEC60335IEC60598IEC60601IEC60669IEC60670IEC60745IEC60884IEC60950IEC60998IEC61058IEC61558

Interested in Sourcing This Product?

Submit a request to connect with verified manufacturers who produce this product.

Ball Pressure Test Apparatus for IEC60335

This ball pressure test apparatus assesses a material's resistance to heat under pressure. It uses a stainless steel ball and spring mechanism to measure indentation depth after a set period at a controlled temperature.

Request a Quote Download PDFPDF

Ball Pressure Test Apparatus for IEC60335 - Image 1
