Autonomous Indoor Delivery Robot
This autonomous mobile robot is designed for indoor delivery. It features advanced sensors, navigation, and multi-layer shelving to improve efficiency and reduce labor costs.
Technical Specifications
Overview
Autonomous Indoor Delivery Solution
This autonomous indoor delivery robot is engineered for high-efficiency logistics in commercial environments such as hospitality, healthcare, and retail. Featuring advanced multi-sensor fusion technology, including Lidar and machine vision, it navigates complex layouts safely and reliably. With a three-layer shelving system capable of carrying 30kg total, it effectively augments staff productivity by handling repetitive delivery tasks.
Performance & Navigation
Key Performance Metrics
15 h
Endurance Time
0.9 m/s
Max Speed
30 kg
Total Capacity
- Navigation Sensors
- LidarMachine VisionDepth VisionInfrared SensorTouch Sensor
- Max Climbing Angle
- 5 °
- Minimum Pass Width
- 70 cm
Physical Specifications
Dimensions & Weight
| Attribute | Value |
|---|---|
| Size | 500mm x 500mm x 1200mm |
| Net Weight | 67 kg |
| Loading Capacity | 10 kg per level (3 levels) |
Power & Connectivity
Battery Specifications
- Capacity: 12Ah
- Voltage: DC 48V
- Charging Time: 4h
- Standby Time: >48h
Charging Mode
AutomaticManual
- Network Interface
- Wi-Fi / 4G
- Rated Power
- 50 W
Durability
- Service Life
- 20000 h
