Technical Specifications
Product Overview
Premium Automotive Casting Turntable
This high-performance casting turntable (Model TD1100-90UA01) is engineered for exceptional reliability and precision in automotive rotation applications. Featuring a robust double ball race bearing design and superior material composition, it delivers consistent movement with ultra-low surface roughness. With an impressive 15-ton load capacity and specialized dust-proof engineering, this component is built to withstand demanding environments.
Key Performance Metrics
Rated Payload
15 ton
Payload Capacity
100 kg
Weight
Technical Specifications
Physical Dimensions
| Attribute | Value |
|---|---|
| Overall Length | 1100mm |
| Overall Height | 90mm |
| Bearing Diameter | 16mm, 22mm |
Precision Standards
- Flatness < 0.15mm
- Ball rail roughness Ra 0.8μm
- Surface roughness Ra 3.2μm
- Superior Radial and Axial clearance (exceeds European standard)
- Material & Construction
- QT5007 Iron with Double Ball Race Bearing
Features & Support
Warranty
15 Month Warranty
- Key Advantages
- Double Course Dust Proof DesignHigh Load CapacityHigh Precision Finish
